Biostar H61MH User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
TH61MU3 / H61 MU3 H61 MH / H61ML
CPU
Socket 1155
Inte l Core i7 / i5 / i3 / Pentium p rocess or
Supports Execute Disab le B it / Enh anced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Inte l Core i7 / i5 / i3 / Pentium p rocess or
Supports Execute Disab le B it / Enh anced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel H61 Intel H61
Super I/O
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main Memory
DIMM Slots x 2
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 8GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 8GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Vers ion 2.0 specif icat ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Vers ion 2.0 specif icat ion co mp liant
LAN
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Realtek RTL8111E (H61MH)
10 / 100 Mb/s / 1Gb/s auto negotiation
Realtek RTL8105E (H61ML)
10 / 100 Mb/s auto negotiation
Sound Codec
ALC662
5.1 channels audio out
High Definition Audio
ALC662
5.1 channels audio out
High Definition Audio
USB3.0
Asmedia ASM1042
PCI Express Gen2 x16 Slot x1 PCI Express Gen2 x16 Slot x1
PCI Express Gen2 x1 Slot x1 PCI Express Gen2 x1 Slot x1
Slots
PCI Slot x2 PCI S lot x2
Printer Port Connector x1 Printer Port Connector x1
Serial Port Connector x1 Serial Port Connector x1
SATA Connector x4 SATA Connector x4
Front Panel Connector x1 Front Panel Connector x1
Front Audio Connector x1 Front Audio Connector x1
On Board
Connectors
S/PDIF out Connector x1 S/PDIF out Connector x1

Biostar H61MH Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DIMM
Maximum Memory	16 GB
Memory Type	DDR3
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
LAN	Realtek RTL8111E Gigabit LAN
Memory Standard	DDR3 1066/1333
Expansion Slots	1 x PCIe 2.0 x1, 1 x PCI
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Video Outputs	1 x VGA
Power Connector	24-pin ATX
