Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
USBKB1
HDMI1
VGA1
DVI1
RJ45U SB1
AUDIO1
ATXPWR2
LAN
CODEC
F_ AUDIO1 J_PRINT1 J_COM1
CIR1
JSPDIFOUT1
F_USB1 F_USB2
PAN EL1
SYS_FAN1
JCMOS1
BIOS
SATA4
SATA2
SATA3
SATA1
BAT1
PCI1
PCI2
PEX16_1
PEX1_1
Super
I/O
ATXPWR1
DDR3_B1
DDR3_A1
CPU_FAN1
Socket 1155
CPU1
H61
Note: ■ represents the 1
st
pin.
