Biostar H61MLC User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
H61 MG C H61 MLC
CPU
Socket 1155
Intel Core i7/i5/i3/Pentium/Celeron processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Intel Core i7/i5/i3/Pentium/Celeron processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel H61 Intel H61
Super I/O
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
Hardware Monitor Controller
Fan Sp eed Controller
ITE's "S mart Guardian " function
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
Hardware Monitor Controller
Fan Sp eed Controller
ITE's "S mart Guardian " function
Main Memory
DIMM Slots x 2
Each DIMM supports 512MB / 1GB / 2GB / 4GB
/ 8GB DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2
Each DIMM supports 512MB / 1GB / 2GB / 4GB
/ 8GB DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spe cif icat ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spe cif icat ion co mp liant
LAN
Realtek RTL8111E (V6.0/6.1/6.2)
Atheros AR8151 (V6.3)
10 / 100 Mb/s / 1Gb/s auto negotiation
Realtek RTL8105E (V6.0/6.1/6.2)
Atheros AR8152 (V6.3)
10 / 100 Mb/s auto negotiation
Sound Codec
VT1708B
5.1 channels audio out
High Definition Audio
VT1708B
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 Slot x1 PCI Express Gen2 x16 Slot x1
Slots
PCI Express Gen2 x1 Slot x2 PCI Express Gen2 x1 Slot x2

Biostar H61MLC Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power fan connector	Yes
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	VIA VT1708B
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows XP, Vista, 7
Supported storage drive interfaces	SATA II
Cables included	SATA
Parallel processing technology support	Not supported
PCI Express slots version	2.0
LAN controller	Realtek RTL8105E
Networking features	Fast Ethernet
BIOS type	-

Weight and Dimensions

Depth	175 mm
Width	226 mm
