Biostar MCP68S Series User Manual

2
throttling mode the beeper sound can be optionally selected to indicate it is in working.
CPU VID--- Shift to Higher Performance
The CPU voltage can be adjusted for the precisely over-clocking of extra demanding
computing performance.
1-2 Specification
Spec Description
Design z
PCB size: 23cm*18cm
Chipset z
MCP 68S Chipset
CPU Socket
z
Support Phenom II x 4
；
Phenom II x 3
；
Phenom II x2
；
Athlon II x4
；
Athlon II x3
；
Athlon II x2
；
Sempron series AM3
CPU under 95W
* for more CPU support information please visit our website
Memory Slot
z
240-pin DDRIII module slot x 2
z
Support 2pcs DDRIII 800/DDRIII 1066/DDRIII 1333
modules expandable to 8GB
z
Dual channel supported
Expansion Slot z
1pcs* PCI-Express x16(by 16 lane) slot
z
1pcs* 32-bit PCI slot
SATA2 RAID
z
Supports four internal Serial ATA ports for four SATA
devices providing 3.0 Gb/sec data transfer rate with RAID
0, 1 functions
LAN Chip
z
Integrated 10/100 LAN chip
z
Supports Fast Ethernet LAN function provide 10/100Mb /s
data transfer rate
6-CH Audio Chip
z
6-channel High Definition Audio CODEC on board
z
Audio driver and utility included
BIOS z
AMI 8MB SMT Flash ROM
Multi I/O
z
PS/2 keyboard and PS/2 mouse connectors
z
VGA Connector x1
z
USB 2.0 port x 2 and headers x2
z
RJ-45 LAN Connector x1
z
Audio connector x1
z
Speaker header x1
z
PWRLED header x1
z
Front panel header x1
z
Serial Port header x1
z
Front Panel Audio headerx1
z
HDMI-SPDIF header x1
1-3 Item Checklist
5
Motherboard
5
DVD for motherboard utilities
5
User’s Manual
5
SATA Cable
5
Back shield
