Biostar MCP68S Series User Manual

3
1-4 Layout Diagram
PS/2 Mouse Port
PS/2 Keyboard Port
RJ-45 LAN Port
VGA Port
Line-IN
Line-OUT
MIC-IN
ATX 12V Power Connecto
r
USB Ports
USB Ports
ATX Power Conn.
Clear CMOS
(JBAT1)
Front Panel Header
USB Headers
(USB1, USB3)
Serial Port Header
Front Panel Audio Header
Speaker Header
Power LED Header
HDMI-SPDIF Header
SATAII Connecto
r
s
(SATA1/SATA2)
SATAII Connecto
r
s
(SATA3/SATA4)
MCP 68S Chipset
SYSFAN1 Header
CPUFAN
Header
CPU Socket
PS2 KB/Mouse Ports
USB Ports
VGA Port
RJ-45 LAN over
USB Ports
Audio Connector
PCI Express x16 By 16 Lane
PCI Slot
