Biostar MCP6P3 User Manual

MCP6P3/N68S3
3
SPEC
Front Audio Connector x1 Supports front panel audio function
S/PDIF out Connector x1 Supports digital audio out function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x1 System Fan Power supply
CMOS clear Header x1 Restore CMOS data to factory default
USB Connector x2 Each connector supports 2 front panel USB ports
Power Connector (24pin) x1 Connects to Power supply
Power Connector (4pin) x1 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
VGA port x1
Serial Port x1
LAN port x1
USB Port x4
Audio Jack x3
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to D-SUB monitor
Provide RS-232 Serial connection
Connect to RJ-45 ethernet cable
Connect to USB devices
Provide Audio-In/Out and microphone connection
Board Size 190 mm(W) x 244 mm(L)
Special
Features
RAID 0 / 1 / 0+1 / 5 support
OS Support Windows XP / Vista / 7
BIOSTAR reserves the right to add or remove support
for any OS With or without notice.

1.4 R
EARPANELCONNECTORS
PS/2
Mouse
PS/2
Keyboard
USBX2USBX2
LAN
COM1 VGA
Line In/
Surround
Line Out
Mic In 1/
Bass/ Center

Biostar MCP6P3 Specifications

General

Brand	Biostar
Model	MCP6P3
Category	Motherboard
Language	English
