Biostar MCP6P3 User Manual

MCP6P3/N68S3
CHAPTER 2: HARDWARE INSTALLATION
2.1 I
NSTALLINGCENTRALPROCESSINGUNIT(CPU )
Step 1: Pull the lever toward direction A from the socket and then raise the
lever up to a 90-degree angle.
Step 2: Look for the white triangle on socket, and the gold triangle on
CPU should point towards this white triangle. The CPU will fit only
in the correct orientation.
5
