Motherboard Manual
4
1.5 MOTHERBOARDLAYOUT
Socket AM3
ATXPWR2
KBMS1
VGA1
USB1
JUSBV1
JKB_PWR
COM1
RJ45USB1
AUDIO1
ATXPWR1
F_AUDIO1
BAT1
Codec
LAN
JPRINT1
JSPDIFOUT1
FDD1
PEX16_1
PCI2
Super I/O
PCI1
SYS_FAN1
PANEL1
SATA1 SATA3
SATA4SATA2
JCMOS1
BIOS
F_USB1
F_USB2
JUSBV2
IDE1
CPU_FAN1
DDR3_A1
DDR3_B1
GeForce
6150 SE/7025
nForce
430/630a
Note: represents the 1■
st
pin.
