Biostar P43D3+ Setup Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C e leron Du al-Core /
Celeron 4xx processor
(Maximum Watt: 125W)
Supports Hyper-Threading / Execute Disable Bit /
Enhanced Intel SpeedStep® / Int el Architecture-64 /
Extended Memory 64 Technology / Virtualization
Technology
FSB 800 / 1066 / 1333 / 1600 MHz (OC) MHz
Chipset
Intel P43
Intel ICH1 0
Super I/O
ITE 8721
Provides the most commonly used leg acy
Super I/O functionality.
Low Pin Count Interface
Env ironment Control in it iatives ,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guard ian" funct ion
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 1333(OC) / 1066 / 800
Registered DIMM and ECC DIMM is not supported
(CPU with FSB 800 MHz only supports DDR3 800)
SATA 2 Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spe cificat ion co mp liant
LAN Realtek RTL8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 Slot x1 Supports PCI-E Gen2 x16 expansion card
PCI Express x1 Slot x2 Supports PCI-E x1 expansion cards
Slots
PCI Slot x3 Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
Printer Port Connector x1 Each connector supports 1 Printer port
SATA Connector x6 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
On Board
Connectors
Front Audio Connector x1 Supports front panel audio function

Biostar P43D3+ Specifications

General

Brand	Biostar
Model	P43D3+
Category	Motherboard
Language	English
