SPEC
S/PDIF o ut co nnector x1 Supports di gital a udio out fu nction
CPU Fan hea der x1
CPU Fan power s upply (with Smart Fa n
function )
System Fan header x1 System Fan Power supply
Clear CMOS head er x1 Restore CMO S data to factory d efa ult
USB connector x2
Each connector supports 2 front panel USB
ports
Power Connector (24pin) x1 Connects to Power supply
Power Connector (4pin) x1 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
Serial Port x1
Printer Port x1
VGA Port x1
LAN port x1
USB Port x4
Audio Jack x3
Connects to PS/2 Keyboard
Connects to PS/ 2 Mo us e
Provide RS- 232 Serial connection
Connects to various types of device
Connects to mo nitor.
Connects to RJ-45 ethernet cable
Connects to USB devices
Provide A udio-I n/Out a nd microphone
connection
Board Size 190 mm (W) x 24 4 mm (L) Micro ATX form Fac tor
OS
Support
Windows 2000 / XP
Biostar Reserves the right to add or remove
support for any OS with or without notice.
1.4 REAR PANEL CONNECTORS
PS/2
Mouse
PS/2
Keyboard
USBX2USBX2
LAN
COM1 VGA
Printer P o rt
Li ne I n /
Surround
Line Out
Mic In 1/
Bass/ Center

Biostar P4M890-M7 SE Specifications

General

Brand	Biostar
Model	P4M890-M7 SE
Category	Motherboard
Language	English
