Abmessungen Typenreihe
Dimensions Série
Dimensioni Gamma
Dimensions Series
Afmetingen Serie
Dimension Series
Wymiary Typoszereg
Размеры Типовой ряд
WX 10 WX 12 WX 13 WX 14
(mm) PN 10 PN 10 PN 10 PN 10
3
/
4
3
/
4
3
/
4
3
/
4
D 1
1
/
4
1
1
/
4
1
1
/
4
1
1
/
4
L 120 120 150 150
H 170 170 200 200
B1 123 123 123 123
B2 60 60 60 60
B3 92 92 92 92
B4 77 77 77 77
T1 133 133 133,2 133,2
T2 30 30 30,5 30,5
T3 103 103 102,7 102,7
4
WX 10
WX 12
WX 13
WX 14
kg 2,4 2,4 2,6 2,6
Abmessungen Typenreihe
Dimensions Série
Dimensioni Gamma
Dimensions Series
Afmetingen Serie
Dimension Series
Wymiary Typoszereg
Размеры Типовой ряд
W 313 W 314 W 315
(mm) PN 10 PN 10 PN 10
3
/
4
3
/
4
3
/
4
…1
1
/
2
D 1
1
/
4
1
1
/
4
2
L 150 150 180
H 200 200 245
B1 146 146 146
B2 64 64 64
B3 109 109 109
B4 92 92 92
T1 152 152 176
T2 25 25 35
T3 127 127 141
W 313
W 314
W 315
kg 444,5
