BIRD 5000 User Manual

Bird Model 5000 Digital Power Meter
24
Specifications
Bird 5000 Digital Power Meter
Display Backlit LCD with major and
minor displays and analog bar
graph
Major Display 5 digits, 5/16” High
Minor Display 5 digits, 1/4” High
Analog Bar Graph 20 segment, horizontal
orientation. Tracks the major
digital display
Measurement Modes Average power, true average
power, or peak power as
determined by the element or
sensor.
Sensor Interface 9-pin D-shell RS-232 serial
connector. Sensor is powered from
the DPM.
PC Interface 9-pin RS-232 serial port
Dimensions 8.0”H x 4.625”W x 2.0”D
(203 x118 x 51 mm)
Weight 2 lbs. (0.9 kg) nominal
Power Supply Rechargeable Nickel-Metal
Hydride (NiMH) battery. Meter
may be operated from ac mains
using supplied adapter.
Battery Life 100 hours, minimum, per charge.
Battery Charge Time 8 hours for full charge.
Operating Temp. 32 to 122 ° F (0 to +50 °C)
