Thruline RF Power Meter, Model 4421
15
Device CLear (DCL)
Function
Resets the status of all devices to an initialized state.
Remarks
Does not change the current interface mode.
The 4421 returns to the factory default condition listed in
Table 6
.
Table 6 IEEE-488 Default Conditions
Selective Device Clear (SDC)
Function
Resets the status of a selected device to an initialized state.
Remarks
Only the device addressed will be cleared.
The 4421 returns to the factory default condition.
Group Execute Trigger (GET)
Function
Initiates a measurement for all devices set to trigger on GET.
Remarks
The 4421 must be already set to trigger on GET.
Used to synchronize measurements of multiple instruments.
Default Condition Related Command
F
orward Carrier Wave FC
Auto Range ON RYY
Two Terminators (CR LF) YT
Prefixes YES PY
Trigger One Shot on Talk Address T1
All SRQ’s OFF M00
Send EOI with last byte of message KY
