BIRO AFMG-52 - Tandem Operation Parts (Up to S;N 52344)

20
PRODUCT MIXER SAFETY COVER UP TO S/N 52100
FRONT OPENING ONLY
Description
Item No.
53446
Lid assembly, up to #52100
HN30S
Hex nut ⅜-16, SS (2 ea.)
51563
Lid hinge pin, up to #52100
53530
Lid lock arm, up to #52100
AN15S
Acorn nut ¼-20, SS (2 ea.)
2503
HHS035S
Hex head screw ¼-20 x ⅝, SS (2 ea.)
Nylon washer .125 thick (2 ea.)
Description
Item No.
FW06S
Flat washer ¼, SS (2 ea.)
56072
Safety cover latch
56073
Latch mounting bracket, L.H.
56074
Latch mounting bracket, R.H.
HNNL15S
Hex nut ¼-20 nylok (3 ea.)
RHS24S
RHS31S
Round head screw ¼-20 x 1, SS (1 ea.)
Roung head screw ¼-20 x ½, SS (2 ea.)
PRODUCT MIXER SAFETY COVER
LID LOCK FEATURE
S/N 54248 ON
RETROFITS ON S/N 52100 TO S/N 54247
Description
Item No.
Fig.
55081
Lid lock retrot kit
S/N 52100 to 54247
55059
Lid lock
55061
Lever arm assembly
2503
Nylon washer .125 thick (2 ea.)
2504
Nylon washer .060 thick (4 ea.)
1
2
3
4
272-8
Acorn nut
5
/16-18, SS (2 ea.)
FHS33S
Flat head screw ¼-20 x ½, SS (2 ea.)
HN15S
Hex nut ¼-20, SS (2 ea.)
5
6
7
Fig.
1
2
3
4
5
6
7
Fig.
8
9
10
11
12
13
14
BACK VIEW
1
2
3
10
11
12
13
14
9
5
4
6
7
8
SIDE VIEW
RIGHT
