BIRO F2000N - Page 19

PAG-4
ABM
F2000N - F3000N - F4000N - B1200N
NSF / ETL VERSION
09400
14700
15400
Complete Assembly
60000
G302
60600
60900
12201
11800
12800
14200
14300
14400
14401
13400
14600
14500
14800
14901
14902
19201-LONG
19202-SHORT
F9319600
CODE DESCRIPTION Q.TY
F9309400 S.S. LONG BELT 1
F9311800 SLIDING SUPPORT 1
F9312201 SCRAPER CONTROL LEVER 1
F9312800 PULLEY PIN 6x30 1
F9313400 CLEANER SPRING 1
F9314200 ARM ASSY 20x187 1
F9314300 RING 1
F9314400 CONVEYOR ROLL 64x140 1
F9314401 SS BELT DRIVER 64 x 140 1
F9314500 ROLL 28x140 1
F9314600 ROLL PIN 12x193 1
F9314700 LOCKING SCREW M8x38 1
F9314800 ROLL BUSHING 1
F9314901 SHORT CONVEYOR ARM 1
F9314902 LONG CONVEYOR ARM 1
F9315400 CONVEYOR ARM PIN 6x30 1
F9319201 LONG CONVEYOR BELT 145x1850mm 1
F9319202 SHORT CONVEYOR BELT 145x840mm 1
F9319600 BEARING 626-2RSH 1
G302 PLAST
IC KNOB D5 6G 1
F93606
00 WIRE CLEANER 1
F9360900 S.S. WIRE 1
CODE DESCRIPTION Q.TY
F9360000 CLEANER ASSEMBLY 1
