MOTOR WIRING AND ELECTRICAL REQUIREMENTS
1. Interchange of motor current is made in motor outlet box. Leads are properly marked. Changing
instructions are on the motor plate or inside junction box cover.
NOTE TO OWNER AND ELECTRICIAN: IF THIS MACHINE IS NOT CORD
AND PLUG CONNECTED TO THE ELECTRICAL SUPPLY SOURCE, THEN IT
SHOULD BE EQUIPPED WITH, OR CONNECTED TO, A LOCKABLE,
MANUALLY-OPERATED DISCONNECT SWITCH (OSHA 1010.147)
4
2. All grinders are wired 208-230 volts unless otherwise specied. Be sure motor specications (voltage,
cycle, phase) match power supply line. Be sure line voltage is up to specication.
3. Connect leads to machine in a manner that will be approved by local electrical inspectors.
4. Rated voltage of the unit shall be identical with full supply voltage.
5. Voltage drop on the supply line shall not exceed 10% of full supply voltage.
7. The feederline conductor shall only be used for the supply of one unit of the relevant horsepower. For
connections of more than one unit on the same feederline, a local electrician will have to be consulted to
determine the proper conductor size.
6. The feederline conductor size in the raceway from the branch circuit to the unit must be correct to assure
adequate voltage under heavy starting and short overload conditions.
8. The size of the electrical wiring required from the power source to the mixer grinder/chopper is a
MINIMUM OF No. 12 WIRE.
9. The BIRO Manufacturing Company is not responsible for permanent wiring, connection or installation.
MOTOR SPECIFICATIONS
HP KW VOLTS HZ PH AMPS
3 2.2 208/230 60 3 9.7/9.4
3 2.2 208/230 60 1 24/21
3 2.2 460 60 3 4.6
2.5 1.9 380/415 50 3 5.3/4.9
