BIS TRADITION - 7 APPENDIX (Specifications, Clearances, Replacement Parts); Specifications; Clearance to Combustibles; 6 Options

38
6. OPTIONS
Gravity kit:
Part No.:
Complete double ducting system including
: 2 elbows 90º, 2
telescopic lengths, 2 grill supports and 2 black grills
7B30ZK-1
Black grill with support
7B30ZO
Brass grill for 7B30ZK-1
7B30ZGB
Elbow 90º, 8" dia.
7B26ZE90
Elbow 45º, 8" dia.
7B26ZE45
Telescopic length, 8" dia.
7B26ZLA
Adjustable length, 8" dia. (2" - 5")
7B26ZL2A
Radiation shield
7B26ZR
Central forced air kit:
Central forced air kit including
: blower (BISZY), flex adaptor
(BISAF), 2 clamps, variable speed control (VRUW), thermo-disk
(VTU), fan to flexible pipe adapter (BISAVF), back draft damper
(BISBD), aluminium tape
BISFWK-1
Fireplace to Flex adaptor and 2 clamps
BISAF
Flexible pipe 5" I.D. x 15 ft. Long
5FLEX15
Flexible pipe 5" I.D. x 30 ft. Long
5FLEX25
Blower 250 CFM for central forced air kit
BISZY
Blower variable speed control with decorative wall plate for (BISZY)
VRUW
Thermo-disk, on/off blower control for (BISZY)
VTU
Fan to flexible pipe adaptor
BISAVF
Heating and cooling thermostat
HCTW
Backdraft damper
BISBD
7. APPENDIX
SPECIFICATIONS
Weight 450 lbs
Height 49 3/8 in.
Width 46 _ in.
Depth 27 in.
Chimney weight S-2100+ (7" dia.) : 12 lb/ft.
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe installation
Side wall (fireplace front): 24" (457 mm) measured from the fireplace side
Ceiling: 6’ 8" (2032 mm) measured from the base of the fireplace
Fireplace enclosure: Bottom: 0”
Side: 0”
Back: 0”
Top: Do not fill the space above the fireplace with any material (Except
the wood framing. See figure 10)
Chimney: 2" (50 mm), except for through ceiling application, ACBI chimney, 1’’
(25 mm) clearance.
Mantel: 56" (1422 mm) measured from the base of the fireplace
REPLACEMENT PARTS
Front refractory bricks PR-SR2421
