15
INSULATED CHASE CONSTRUCTION
Figure 11
Nailing Flanges
Four nailing flanges are provided to secure the
fireplace on the floor (see figure beside).
Bend the nailing flanges down so each flange
is flush with the floor, then using nails or
screws, secure the fireplace to the floor (2
places each side). The heads of the screws
must be large enough to cover the holes on the
nailing flanges.
Unbend to floor
and nail/screw
