34
6. OPTIONS
Gravity kit:
Part No.:
Complete double ducting system including: 2 elbows 90º, 2
telescopic lengths, 2 grill supports and 2 black grills
7B30ZK-1
Black grill with support 7B30ZO
Brass grill for 7B30ZK 7B30ZGB
Elbow 90º, 8" dia. 7B26ZE90
Elbow 45º, 8" dia. 7B26ZE45
Telescopic length, 8" dia. 7B26ZLA
Adjustable length 8" dia. (2" - 5") 7B26ZL2A
Radiation shield 7B26ZR
Central forced air kit:
Central forced air kit including: blower (BisZY), flex adaptor
(BISAF), 2 clamps, variable speed control (VRUW), thermo-disk
(VTU), fan to flexible pipe adapter(BISAVF), backdraft damper
(BISBD), aluminium tape
BISFWK-1
Fireplace to Flex adaptor and 2 clamps BISAF
Flexible pipe 5" I.D. x 15 ft. Long 5FLEX15
Flexible pipe 5" I.D. x 30 ft. Long 5FLEX25
Blower 250 CFM for central forced air kit BISZY
Blower variable speed control with decorative wall plate for (BISZY) VRUW
Thermo-disk, on/off blower control for (BISZY) VTU
Fan to Flexible pipe adaptor BISAVF
Heating and cooling thermostat HCTW
Backdraft damper BISBD
Fireplace:
Panel for clean face option BUCF
Rigid firescreen BUCEBWZN
Heat activated on/off pre-wired fan kit UZY3
Masonry chimney adaptor BISUMA
Outside air kit UZI
7. APPENDIX
SPECIFICATIONS
Weight 385 lbs
Height 36"
Width 36"
Depth 24 1/2"
Chimney weight ASHT+ (6" dia.) : 6.25 lb/ft.
Chimney weight S-2100+ (6" dia.) : 10.8 lb/ft.
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe installation
Side wall: 17" (324 mm) measured from the fireplace side
Ceiling: 6’ 8" (2032 mm) measured from the base of the fireplace
Fireplace enclosure: Bottom: 0” Side: 0” to spacers Back: 0” to spacers
Top: Do not fill the space above the fireplace with any material (Except
the wood framing. See page 13, Figure 8)
Chimney: 2" (50 mm)
Mantel: 45" (1143 mm) measured from the base of the fireplace
