BIS Ultima - Parts, Options, and Appendix; Parts and Components List

33
5. PARTS AND COMPONENTS LIST (AC Chimney)
Description Part No.
Lengths 6" dia.
12" length AC 6L12
18" length AC 6L18
36" length AC 6L36
48" length AC 6L48
15º elbow AC 6E15
30º elbow AC 6E30
Rain cap AC 6CPR
Spark arrester screen PE+
Supports
Offset support XSO+
Support section AC 6SL
Roof support XST+
Starter section AC 6SB
Roof brace XBS2+
Wall band XBM+
Firestop
Firestop AC BF
Radiation shield AC RS
Attic radiation shield AC RSA
Wall radiation shield 30º AC RSM30
Insulated wall radiation shield 30º AC RSMI30
Wall radiation shield 45º AC RSM45
Insulated wall radiation shield 45º AC RSMI45
Outside air kit (chimney) AC ZI
(flex, insulation, outside register and coupling)
Flat roof flashing ACF
Adjustable roof flashings
1/12 - 7/12 (5º - 30º) AC FA
8/12 - 12/12 (30º - 45º) AC FB
12/12 - 21/12 (45º - 60º) AC FBB
Peak roof flashings
1/12 - 7/12 (5º - 30º) AC FP
8/12 - 12/12 (30º - 45º) AC FPB
Storm collar AC FC
