Bitronics M350 User Manual

ML0038 September 27, 2017 - 14 - Copyright 2017 Bitronics, LLC
Communication Ports
Serial (option*) RS-232, RS-485, Software configurable ports
Baud rate: 9600 bps to 115.2 kbps
Ethernet Single port; copper 10/100 Base-TX (standard)
Single port; LC fiber 100 Base-FX (option)
Analog Transducer
Outputs
(
option*
)
Refer to section 7.0 for specifications
*Either the serial port or analog output may be ordered as an option, but not both
Accuracy
A
ccuracies are specified at nominal Frequency and 25C, (unless otherwise noted). Unless noted, all values are true RMS
and include Harmonics to the 63rd
(
minimum
)
.
Voltage AC: Better than 0.1% of reading (20 to 150 V rms, input-to-case).
(
+/- 25ppm/De
g
C
)
Current Input option 1
(Internal Isolation -
1A ac)
Better than 0.1% of reading +/- 20uA (>0.1A to 2.0A, -20C to 70C)
Better than 0.1% of reading +/- 50uA (0.01A to 0.1A, -20C to 70C)
Minimum reading 1mA
Input option 5
(Internal Isolation -
5A ac)
Better than 0.1% of reading +/- 100uA (>0.5A to 10.0A, -20C to
70C
)
Better than 0.1% of reading +/- 250uA (0.05A to 0.5A, -20C to 70C)
Minimum reading 5mA
