ML0038 September 27, 2017 - 16 - Copyright 2017 Bitronics, LLC
Physical
Connections
Protective
Conductor
Terminal
10-32 Studs for connection with protective earth ground. Recommended Torque: 12 In-Lbs,
1.36 N-m
Cable temperature ratin
: 85C minimum
Current
(CT) Model
3 Onl
10-32 Studs for current inputs. Recommended Torque: 12 In-Lbs, 1.36 N-m
Cable temperature rating: 85C minimum
Voltage
(VT) &
(AUX
PWR)
Terminal Block accepts #22-10 AWG (0.35 to 5mm
2
) wire, or terminal lugs up to 0.375"
(9.53mm) wide. Precautions must be taken to prevent shorting of lugs at the terminal block.
A minimum distance of 1/8" (3mm) is recommended between uninsulated lugs to maintain
insulation requirements. Recommended Torque: 9 In-Lbs, 1.02 N-m
Cable temperature ratin
: 85C minimum
Serial Port
6 position removable terminal block, accepts 26-14AWG solid or 26-12 AWG stranded wire.
Recommended Torque 7 in-lbs, 0.79 N-m.
Cable temperature ratin
: 85C minimum
Ethernet RJ45, 8 position modular jack, Category 5 for copper connection; 100m (328 ft.) UTP
unshielded twisted pair
cable.
Weight
t
pical
1.8 lbs (.8 kg)
Size Industry standard 4” round case, 7.0 inches long
