KW-210-2 25
15. Applying the heat transfer paste
Turn the frequency inverter front side down.
Have the heat transfer paste and putty knife ready.
It is recommended wearing gloves when applying
the heat transfer paste.
Apply the heat transfer paste onto the shown area
on the rear side of the frequency inverter and distrib-
ute it uniformly using a putty knife.
16. Screwing the frequency inverter to the
compressor
Screw the FI to the compressor with the 4 screws
and a 6mm hexagon socket screw spanner (tighten-
ing torque 20 Nm).
