BIXOLON SLP-TX220E - Using Fan-Fold Paper

Rev. 1.00
- 32 -
SLP-TX220x/TX223x
5-13 Using Fan-Fold Paper
Supplying paper to the printer externally is done as follows.
5-13-1 Printer Preparation
Remove the rear paper supply cover on the back side of the printer with a knife or other
cutting instrument.
※ CAUTION
- Take care not to injure the hands and/or any other part of the body when performing
this step.
5-13-2 When using Fan-Fold paper
1) Insert the paper at the rear of the printer using the slot and guides.
2) Adjust Paper Holders to the paper width by using the Fix Tool.
5-13-3 When using Large-Capacity paper roll (Option)
Remove
Fix Tool
Paper Holder
External Paper Supplier
(LES-400G)
