BIXOLON SLP-TX220E - Paper Installation

Rev. 1.00
- 14 -
SLP-TX220x/TX223x
3-3 Paper Installation
1) Open the Paper Cover.
2) Spread the Paper Holder and insert paper
roll.
3) Whether the paper label is wound 4) Adjust the paper guide to the width of
inwards or outwards, its printing the paper.
surface must face up.
5) If you use Black-Mark or Notch paper roll, please lift up the paper and match the sensor
position adjust the black mark or notch hole.
6) Close the Paper Cover until a click sound is heard.
Moveable Black-Mark Sensor
and Notch Sensor
●
●
Paper Guide
Paper Cover
Paper Holder
