BIXOLON SPP-R200II Connection Manual

Rev. 1.00
- 19 -
Mobile Printer
5. Configuration
WLAN Setting Values
Classification
Item
Remarks
Input Range
Home
WLAN setting status display
System
Printer Name
Printer Name
0~32 letters
Printer Port
TCP Raw port that the printer can
use
0~32767 integers
(except21,23,25,80,443,3318)
User Name
ID to use for ftp, telnet, web-
server log-in
1~32 letters
User Password
Password to use for ftp, telnet,
web-server log-in
1~32 letters
Confirm Password
Confirm Password
1~32 letters
Protocol
WebServer SSL
Set whether to use HTTPS
Http cannot be used when using
Https
Enable/Disable
TELNET
Set whether to use Telnet
Enable/Disable
FTP
Set whether to use FTP
Enable/Disable
SNMP
Set whether to use SNMP
Enable/Disable
Network
Network Mode
Wireless LAN operating mode
Infrastructure/Adhoc
Adhoc Channel
Channel when creating Adhoc
network
1~14
SSID
ID of the AP to connect
1~32 letters
Inactivity Time
TCP connection hold time
0~3600 integer
IP Assignment
Method
IP Assignment Method
DHCP/Manual
IP Address
Printer IP
IP Address
Subnet Mask
Subnet mask
IP Address
Gateway
Default Gateway
IP Address
Authentication
Authentication
Wireless LAN authentication
method
open, shared,
wpa1/2-psk, wpa1/2
Cryptograph
Wireless LAN encryption method
none, WEP64/128,TKIP, AES
EAP Mode
Authentication method
PEAP, TLS, LEAP, FAST, TLS
WEP Key
Key for WEP encryption method
WEP64 (5 Ascii, 10 Hex)
WEP128 (13 Ascii, 26 Hex)
PSK Key
Key for PSK encryption method
1~64 letters
Authentication ID
ID for EAP Authentication
1~32 letters
Authentication PW
Password for EAP Authentication
1~32 letters
Wizard
Setting wizard for each step

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
