BIXOLON SPP-R200II Connection Manual

Rev. 1.00
- 41 -
Mobile Printer
8. Facroty Reset
This function changes the WLAN settings of the printer to the initial factory
settings.
Method
To set Factory reset mode, printer should be in Hexa Dump mode.
1) Hex dump mode
After turning off the power, open the cover.
Turn on the printer while holding down the feed button like self test mode. Then close the
cover to enter hexa dump mode. The below message is printed.
Hexadecimal Dump
To change WLAN setting values factory default
Press POWER button three times!!
To terminate hexadecimal dump
Press FEED button three times!!
Push the Power button 3tiems,WLAN setting will be reset as a factory default and below
message is printed.
*** WLAN Factory Reset Completed! ***
*** Please Reboot Printer ***
< Online Hex Dump Completed >
After turning off the printer and on, WLAN setting will be factory default.
Power
FEED

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
