BIXOLON SPP-R200II Connection Manual

Rev. 1.00
- 4 -
Mobile Printer
3. Specifications
CATEGORIES
FEATURE
IMPLEMENTATION
Wireless
Specification
Wireless
Standard
IEEE802.11b, IEEE802.11g
Frequency
Range
2.412~2.484GHz
Channels
1 ~ 14 channels
Max Transmit
Power
802.11b: max. 18dBm(@11Mbps)
802.11g: max. 15dBm(@54Mbps)
Receive
Sensitivity
802.11b: min. -76dBm(@11Mbps)
802.11g: min. -65dBm(@54Mbps)
Data Rates
802.11b : 1M ~ 11 Mbps (TBD)
802.11g : 6M ~ 54 Mbps (TBD)
Modulation
Schemes
802.11b – BPSK, QPSK, CCK, DSSS
802.11g – BPSK, QPSK, 16-QAM, 64-QAM, OFDM
Range
Up to 100m free space (Outdoor)
Connection
Modes
Infrastructure and Ad-hoc (IBSS)
Security
Open Connection
Shared Key(WEP encryption 64 and 128 bit options)
WPA-PSK, WPA2-PSK
WPA1/2 Enterprise
(EAP-TLS, EAP-TTLS, PEAP, LEAP, FAST)
SSL2 / SSL3 / TLS1
Internet
DHCP Client, HTTP, HTTPS, TELNET, FTP, ARP,
ICMP, SNMP, IPv4, TCP, UDP
Operation
Mode
Infrastructure , Ad-hoc
Management
WLAN Configure tool, HTTP, HTTPS, TELNET, FTP

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
