BIXOLON SRP-275II Windows Driver Manual

SRP-275II
Rev. 1.05
- 30 -
7-2 Use of WordPad
7-2-1 WordPad Environment Settings
Launch WordPad, set the printing related options as follows, and test the printer with
WordPad.
- Select printer
Select “Print” from the “File” menu, and select the printer (BIXOLON SRP-275II).
- Set paper size, orientation, margin, etc.
Select the “Page Setting” from “File” menu, and set paper size, orientation, and margin.
7-2-2 Text Printing
Print the text from WordPad using the Windows driver of the printer.
1) Select the desired font from the Font menu (FontA1x1).
2) Select the desired font size (9).
3) Enter the text to be printed in WordPad.
4) Click the Print button in the toolbar to print.

BIXOLON SRP-275II Specifications

General

Type	POS printer
Print speed	5.1 lps
Maximum resolution	80 x 144 DPI
Maximum roll diameter	85 mm
Supported paper width	76.5 mm
Maximum printing width	63.5 mm
Flash memory	2 MB
RAM capacity	0.008 GB
Autocutter durability	1.5 million cuts
Built-in sensors details	Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
AC input voltage	100-240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Mean cycles between failures (MCBF)	18000000
Product color	Black
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	239 mm
Width	160 mm
Height	157 mm
Weight	2400 g
