BIXOLON SRP-E300 User Manual

SRP-E300/E302
Ver. 2.00
- 15 -
2-2-3 Serial (9-pin) Interface
- SRP-E300ES/E302ES
Pin No.
Signal Name
Direction
Function
1
NC
-
-
2
TxD
OUTPUT
Transmit Data
3
RxD
INPUT
Receive Data
4
DSR
INPUT
Data Set Ready
5
GND
-
-
6
DTR
OUTPUT
Data Terminal Ready
7
CTS
INPUT
Clear To Send
8
RTS
OUTPUT
Ready To Send
9
NC
-
-
Connect or disconnect the communication cable while the printer
power is off. If power is on, your data may be lost.
Serial (9-pin) Port

BIXOLON SRP-E300 Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum roll diameter	83 mm
Supported paper width	80 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Product color	Black
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Internal memory	- MB
Built-in barcodes	1D, 2D, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.5 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	182.4 mm
Width	132 mm
Height	128.5 mm
