BIXOLON SRP-E300 User Manual

SRP-E300/E302
Ver. 2.00
- 29 -
7. Maintenance
7-1 Paper Jam
• If paper is stuck, turn the printer ON/OFF and open the cover to remove the crumpled
paper inside the printer. If the Printer Cover will not open, please follow the following
instructions.
1) Turn the printer OFF.
2) Pull out the Cutter Cover to separate from the printer.
3) Turn the knob and insert the blade that sticks out using a cross-head screwdriver as
shown below.
4) Push the cover-open button and remove the jammed paper.
5) Put the Cutter Cover back in place.
6) Turn the printer ON and use it.
If the cover does not open, do not forcibly open it.
It may result in poor paper cutting or printer damage.
- Placing your hand above the printer outlet may cause a paper jam.
- In case of a minor jam, it may be possible that the operating
blade returns to the original position by turning the printer
OFF and then back ON.
Knob
Cutter Cover

BIXOLON SRP-E300 Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum roll diameter	83 mm
Supported paper width	80 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Product color	Black
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Internal memory	- MB
Built-in barcodes	1D, 2D, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.5 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	182.4 mm
Width	132 mm
Height	128.5 mm
