BIXOLON SRP-E300 User Manual

SRP-E300/E302
Ver. 2.00
- 25 -
5. Self-Test
The self-test checks whether the printer has any problems.
If the self-diagnostics reveal no error in the printer, please see other device or software.
If the printer does not run normally, please contact the place of purchase.
- Do not open the top cover while the printer is running.
- If the printer does not run normally, please contact Customer
Center.
1) Make sure paper roll has been installed properly.
2) Turn on the power while holding down the FEED button and the self-test begins.
3) The self-test prints the current status of the printer including control ROM version.
4) After printing the current printer status, the printer wait for the next step after
printing the following lines. (The error signal light keeps blinking.)
SELF-TEST PRINTING.
Select a button to run the following.
Continue test printing : Press the button briefly
Memory switch configuration mode : Press and hold down button
5) Press the Feed button to resume printing or hold down the button for at least one
second to change the VMSM settings.

BIXOLON SRP-E300 Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum roll diameter	83 mm
Supported paper width	80 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Product color	Black
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Internal memory	- MB
Built-in barcodes	1D, 2D, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.5 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	182.4 mm
Width	132 mm
Height	128.5 mm
