BIXOLON SRP-E300 User Manual

SRP-E300/E302
Ver. 2.00
- 30 -
7-2 Cleaning Printer
• The presence of dust, foreign matter, adhesive matter, or other pollutants inside the
printer’s head and internal capacity may undermine printing quality.
It is recommended to clean printer at every paper roll change.
1) Open the Printer Cover and remove the paper currently in use.
2) Residue or contamination of TPH should be wiped out by alcohol for medical.
3) Insert a paper roll and close the Printer Cover.
- Be sure to clean after turning the printer off.
- Be careful not to leave scratches in the print head the printer may be
damaged.
- Print head is very hot while the printer is printing, so clean the printer
after cooling it sufficiently with power off.
- Do not touch heated area of print–head when cleaning.
Personal injury may result from static electricity, etc.

BIXOLON SRP-E300 Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum roll diameter	83 mm
Supported paper width	80 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Product color	Black
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Internal memory	- MB
Built-in barcodes	1D, 2D, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.5 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	182.4 mm
Width	132 mm
Height	128.5 mm
