BIXOLON SRP-E300ESK - Interface; USB Interface

Ver. 1.00
- 6 -
SRP-E300/E302
1-2 Interface
• Connect the printer to the host computer using the right interface cable that complies with
the specifications of the interface
1-2-1 USB Interface
- SRP-E300/E302 - SRP-E300ES/E302ES
Pin No.
Signal Name
Designation (Color)
Function
Shell
Shield
Drain Cable
Frame Ground
1
VBUS
RED
Host Power
2
D-
WHITE
Data Line (D-)
3
D+
GREEN
Data Line (D+)
4
GND
BLACK
Signal Ground
Caution
All cables must be connected while the product is turned off.
USB Port
USB Port
