BIXOLON SRP-E300ESK - Serial Interface

Ver. 1.00
- 8 -
SRP-E300/E302
1-2-3 Serial Interface
- SRP-E300ES/E302ES
Pin No.
Signal Name
Direction
Function
1
NC
-
-
2
TxD
OUTPUT
Transmit Data
3
RxD
INPUT
Receive Data
4
DSR
INPUT
Data Set Ready
5
GND
-
-
6
DTR
OUTPUT
Data Terminal Ready
7
CTS
INPUT
Clear To Send
8
RTS
OUTPUT
Ready To Send
9
NC
-
-
Caution
All cables must be connected while the product is turned off.
Serial Port
