APPENDIX B : Specification
Printing method Thermal line printing
Dot density 200 x 200 Dpi (8 dot/mm)
Printing width 48mm
Paper width 58mm
Characters per line 32 (Font A) (12x24) , 42 (Font B) (9x24)
Printing Speed
Approximately 1.97 inchs / sec
50 mm/sec
at 25 /printing duty 12.5%℃
Receive buffer size 15K bytes
Supply voltage DC 24V 1.5A
Temperature
0 ~ 40 (operating)℃
-10 ~ 50℃ (storage)
Environmental
conditions
Humidity
30 ~ 80% RH (operating)
10 ~ 90% RH (storage)
Mechanical 15,000,000 line
MCBF
Head 50 million pulse (about 50km)
※ Paper
- Paper thickness : 0.06 ~ 0.09mm
- Roll size : Ø60 ~ 57 (w)
- Roll spool diameter
1) Inside : Ø12mm (0.47”)
2) Outside : Ø18mm (0.71”)
53
※Option : STP-103DK
1) Serial Interface Connector Specification
PRINTER HOST
19 RXD (I) ----------------------------------- 3 TXD (O)
20 TXD (O) ----------------------------------- 2 RXD (I)
18 RTS (O) ----------------------------------- 8 CTS (I)
21 CTS (I) ----------------------------------- 7 RTS (O)
4 DTR (O)
6 DSR (I)
FGND FGND
22~25 SG ----------------------------------- 5 SG
9 PINE FEMALE
* RJ11 6P
22 SG ---- 1 GND
14 SOL1 ---- 2 SOL1
16 COMPS/W ---- 3 COMPS/W
17 SLCT ---- 4 SLCT
5 NC
22 SG ---- 6 GND
25 PINE MALE
6
1
CONNECT
