OUTPUT VOLTAGE
OUTPUT CURRENT
CUMNF&~
LOAD REGULATION
FULLY SOLID STATE
CURRENT LIMITING/
OVERLOAD
PROTECTION
SIMPLIFIED
ZZll&TING
(0-50 VDC
0-2
AMPS
DUAL
METERS
SPECIFICATIONS
O-SO VDC, continuously
var-
iable. Two ranges,
0-25
and
O-50 VDC.
O-2 amperes. Four ranges:
O-SO
mA,
0-0.2A.
0-0.5A,
and
0-2A.
5% to 100% of each current
range.
Maximum 0.1%. typical
0.07%.
LINE REGULATION
RIPPLE
CURRENT DERATING
SIZE
NET WEIGHT
FEATURES
Uses integrated circuits, sil-
icon transistors and diodes,
and an SCR. All the advan-
tages of solid state construc-
tion are utilized, including:
Dependability-reliability
No warm up time or stab-
ilization delay
Ruggedness
Compact size
Protects load and instrument
against overload.
Curr
ent
limit is fully adjustable from
approximately 2.5
mA
to 2
A. The power supply auto-
matically shuts down and
the OVERLOAD lamp lights
if the preset current limit is
exceeded. After clearing the
cause of the overload, sim-
ply push the set/reset button
to restore normal operation.
Permits setting current limit
without disturbing external
load connections or output
voltage settings: does not
re-
quire
application of short
circuit to output terminals.
Simply
push the set/reset
button and adjust the
cur-
rent limit while reading the
setting on the current meter.
Continuously adjustable over
entire range with a single
control; no range switching
required.
Divided into four ranges.
Fully regulated output at all
current levels.
Allows output voltage and
current to be monitored si-
multaneously without
switch-
ing
ranges from current to
voltage. Both meters have
overload protection to pre-
vent damage from incorrect
range selection.
FOUR CURRENT
METER RANGES
TWO VOLTMETER
RANGES
STANDBY-DC
ON SWITCH
ON-OFF CONTROL
PILOT LAMP
MECHANICAL
PREREGULATOR
FLOATING OUTPUT
REVERSE POLARITY
PROTECTION
BINDING POSTS
ATTRACTIVE
APPEARANCE
EASY TO OPERATE
Maximum 0.1%. 0.02%
typ-
ical, at output Voltage of
50
VDC and output current of 2
amps
from
105-125
VAC.
5
millivolts peak-to-peak
maximum.
.02
A/°C
above
25°
C am-
bient.
(2
A Range only).
14 1/8"
x
3 7/8"
x 10” deep.
11 lbs.
Provides maximum meter
resolution. Selection of me-
ter range also selects coarse
current limit setting.
0-25V and
0-5OV
ranges pro-
vide maximum meter resolu-
tion. A mechanical stop
prevents the voltage level
control from exceeding
ap-
proximately 25 volts when
the O-25 V range is selected.
Standby mode disconnects
power
supply from load
without disturbing voltage
or current control settings.
On-off switch is combined
with voltage level control to
assure voltage setting of
zero when unit is turned on.
Lights to indicate at a glance
that the unit is turned on.
Power supply’s rectifier in-
put voltage increases in pro-
gressive steps as output
voltage setting is increased.
Improves efficiency; less
power is converted to heat
at low voltage operation.
Permits referencing the posi-
tive or negative output to
any external dc potential or
ground.
Protects against accidental
damage from reverse polar-
ity connection to external
power source.
Heavy duty
5-way
binding
posts for positive cmd
nega-
tive polarity output and earth
ground.
Modem, functional design.
When more
than
one unit
is
used, units may be stacked.
All controls are
identified
and easy to read. Simplified
operation helps prevent op
erator
mistakes that might
damage equipment.
