INTRODUCTION
The B
&
K
Precision Model 1601 Regulated DC
Power Supply is a versatile, laboratory quality in-
strument which provides regulated dc voltage and
current outputs of 0 to 50 volts and 0 to 2 amperes
respectively. Its high specifications, operating ease,
and special features make it an excellent choice
for most applications requiring a dc power source.
It is especially well suited for powering transis-
torized and fully solid state electronic equipment
such as automobile radios and sound systems, bat-
tery operated radio receivers, portable radios,
mobile citizen’s band transceivers and Walkie-Talkie
transceivers.
The following list is ‘but a small sample of the
most popular applications for the instrument:
-Service Technicians
-Factory Technicians
-Engineers and
Laboratory
Technicians
-Electronics
Instructors
and Students
CONTROLS AND INDICATORS
Powering equipment or indi-
vidual circuits during testing
and trouble-shooting in the
service shop.
Powering complete
equip-
ments or individual assem-
blies during testing in the
factory.
Powering prototype and ex-
perimental circuits and
equipments.
Laboratory exercises in basic
and
advanced electronics.
3
2
1
13
12
11
io
Controls and Indicators
1 current meter
Measures actual output load
4 Push to set
current during normal oper-
CURRENT
ation.
LIMIT or to reset
Indicates current limit value
OVERLOAD
when set/reset button 4 is
button (set/
pushed. reset button)
2 CURRENT
Selects range for current
RANGE switch
meter 1 and coarse setting
of current limit. Full scale
meter
reading
and maxi-
mum current limit of:
0.05A
position
0.2A
position
0.05 ampere
(50
milliamps)
0.5A
position
0.2 ampere
(200
milliamps)
2A position
0.5 ampere
(500
milliamps)
2 amperes
5 OVERLOAD
indicator
(red)
6 POWER indicator Lights continuously while
power supply is turned on.
7 STBY-DCON
switch;
STBY position
l
3 SETCURRENT
LIMIT control
Fine adjustment of current
limit setting. Continuously
adjustable from 5% to 100%
of range which is selected
by CURRENT RANGE switch
2
DC ON position
4
When fully depressed and
held, connects current meter
1
to read the current limit
setting. When pressed and
released, resets overload cir-
cuit if it has been tripped.
Lights when current limit has
been exceeded and power
supply output has shut down.
Removes power from output
terminals 9 and 10 and
voltmeter
11 but leaves
power supply activated in a
standby condition.
Applies power to output ter-
minals 9 and
10
and
voltmeter
11
To Next Page
