2. INSTALLATION
2-1. Initial Inspection
This instrument was carefully inspected both mechanically and electrically
before shipment. It should be physically free of damage. To confirm this, the
instrument should be inspected for physical damage which may have occurred in
transit. Also, verify that all supplied accessories have been included.
2-2. Connecting AC Power
This instrument requires 115V AC or 230V AC (50-60 Hz) power socket with
protective earth contact (PE-contact). If it is available only a power socket without
PE-contact (so a 2-conductor ac power) then a power socket with PE-contact must
be installed before or the appliance should be provided with a PE-screw-terminal
which is not soluble by hand and not soluble before 2-conductor power lines.
CAUTION
AC POWER OF THIS INSTRUMENT IS PRESET TO 115V IN FACTORY.
BEFORE POWERING ON THIS INSTRUMENT, CHECK AND MAKE SURE
THE VOLTAGE OF THE POWER SOURCE IS SAME WITH THE MARKING OF
UNIT.
IN CASE OF AC230V, VOLTAGE SELECTOR (on rear panel) SHOULD BE
SELECTED TO 230V POSITION.
2-3. Cooling and Ventilation
No special cooling and ventilation is required. However, the instrument should be
operated where the ambient temperature is maintained.
2-4. Position
This instrument is built as a bench-type instrument with rubber feet and tilt stand
in place. The stand-up angle can be adjusted by changing the angle of the carrying
handle.
2-5. Warming-Up
DANGEROUS VOLTAGE
AC-ALTERNATING CURRENT
DC-DIRECT CURRENT
SEE EXPLANATION IN MANUAL
GROUND
FUSE
To Next Page
