7
- DC CURRENT
Range Resolution Accuracy Over Load Protection
2 mA
20 mA
200 mA
100 nA
1 uA
10 uA
±(0.75% + 5d)
2 A 100 uA ±(1.0% + 5d)
2A/250V
20 A 1 mA ±(1.0 % + 10d) 15A/250V
20A Range for 15 seconds max during each 15 minute period
- AC CURRENT
Range Resolution Frequency Accuracy
Over Load
Protection
2mA
100 nA
40Hz to 50Hz
±(1.5% + 10d)
2A/250V
20mA
1 uA
50Hz to 60Hz
±(0.75% + 10d)
200mA 10 uA 60Hz to 1kHz
±(2.0% + 10d)
1kHz to 5kHz
±(3.0% + 10d)
2000mA 100 uA 40Hz to 50Hz
±(1.5% + 10d)
50Hz to 60Hz
±(1.0% + 10d)
60Hz to 1kHz
±(2.0% + 10d)
1kHz to 5kHz
±(3.0% + 10d)
20A 1mA 40Hz to 50Hz
±(1.5% + 10d)
15A/250V
50Hz to 60Hz
±(1.0% + 10d)
60Hz to 1kHz
±(2.0% + 10d)
1kHz to 2kHz
±(3.0% + 10d)
20A Range for 15 seconds max during each 15 minute period
