BK Precision 4053B User Manual

54
• The width deviation cannot exceed the current pulse width.
• The width deviation is limited by the minimum pulse width and current edge time setting.
Duty Deviation represents the variation (%) of the modulated waveform duty cycle relative to
the original duty cycle. Press Duty Dev to highlight the parameter and use the numeric
keyboard or knob to input the desired value as shown in the Figure 37.
• The duty deviation cannot exceed the current pulse duty cycle.
• The duty deviation is limited by the minimum duty cycle and current edge time setting.
Figure 36 - Width Deviation Setting Interface
Figure 37 - Duty Deviation Setting Interface

BK Precision 4053B Specifications

General

Brand	BK Precision
Model	4053B
Category	Portable Generator
Language	English
