71
Setting HI and LO Limits
The yellow keys from the front key buttons are used
for setting HI and LO limits for compare testing. The
button enters the HI/LO limit setup menu.
The arrow buttons , , , and
are used to adjust the HI/LO sets and HI/LO
limit values. The button is used to save the
adjusted limit values.
Follow the below procedure to configure HI/LO limits.
1. Press and hold for two seconds to
enter HI/LO limit setting mode.
2. The secondary display will flash “L01” and the
primary display will indicate the limit value.
Default is displayed as “0090”. This indicates
the limit value for the first set for the “LO” limit.
Use the or button to select the
digits of the limit value, going left or right
respectively. The digit that is blinking rapidly
indicates the current selection.
