18
6. Θ – *Phase angle indicator for secondary
display
7. Q – Quality factor indicator
8. ESR – *Equivalent series resistance indicator
9. – Secondary display
10. – Beeper tone indicator for tolerance
mode
11. deg – *Phase angle degree indicator
12. Ω – *ESR(ohm) units indicator
13. % - Tolerance percentage indicator
14. kHz – Frequency units indicator
15. PAL – Parallel mode indicator
16. SER – Series mode indicator
17. – Inductance units (Henry) indicator
18. – Capacitance units (Farad) indicator
19. MkΩ – Resistance units (Ohm) indicator
20. RMT – Remote mode indicator
21. – Primary display
22. D – Dissipation factor indicator
23. DH – Data hold indicator
24. AUTO – Auto-ranging indicator
25. TOL – Tolerance mode indicator
26. – Low battery indicator
27. @OFF – Auto power-off indicator
28. 1%5%10%20% - Tolerance sorting
percentage indicator
