Chapter 4: Operation
Table 4-1 (continued). RS-232 commands.
EDID Commands
Command Function Feedback Example
50772% EDID passthrough EDID: bypass mode
50773% Set EDID passthrough EDID:1080P&PCM 2ch
50774% Set EDID data to 1080P Dolby 5.1 EDID:1080P&5.1ch
50775% Set EDID data to 1080P3D Dolby 5.1 EDID:1080P3d&5.1ch
50776% Set EDID data to 1080i PCM 2.0ch EDID:1080i&PCM 2ch
50777% Set EDID data to 4K*2K PCM 2.0ch EDID:4K&PCM 2ch
50778% Check EDID data EDID:1080P&PCM 2ch
EDID:1080P&5.1ch
EDID:1080P3d&5.1ch
EDID:4K&PCM 2ch
50799% Program EDID file, send EDID data
within 10s
Waiting for edid within 10
secs!
NOTES:
1. EDID commands are for HDMI sources only.
