Page 21
877-877-2269 | blackbox.com
Chapter 4: Operation
Table 4-1 (continued). RS-232 commands.
Setup Commands (continued)
Command Function Feedback Example
50617% Reset to factory default. —
Inquire Commands
Command Function Feedback Example
50632% Check the output resolution . Resolution: xx
50633% Check the picture mode. Picture Mode: xx
50793% Check HDCP status. HDCP Off
HDCP On
HDCP Active
50635% Check the image aspect ratio. Aspect Ratio: xx
50636% Check the brightness. Brightness: xx
50637% Check the contrast. Contrast: xx
50638% Check the saturation. Saturation: xx
50639% Check sharpness. Sharpness: xx
50640% Check the color temperature. Color Temperature: xx
Adjustment Commands
50678% Enable screen output adjusting. Enter Output Position Adjust
50679% Disable screen output adjusting. Exit Output Position Adjust
50670% Move the image to left. Output Position Adjust X xx
50671% Move the image to right. Output Position Adjust X xx
50672% Move the image up. Output Position Adjust Y xx
50673% Move the image down. Output Position Adjust Y xx
50674% Stretch left from left side (increase
image width).
Output Width Adjust xx
50675% Pull right from left side (decrease
image width).
Output Width Adjust xx
50676% Stretch upwards from bottom side
(decrease image height).
Output Height Adjust xx
50677% Stretch downwards from bottom
side.
Output Height Adjust xx
(increase image height)
