7
CHAPTER 1: Specifications
Maximum
Distance — Between device and Converter (RS-232):
50 ft. (15.2 m);
Between Converters (RS-422/530):
4000 ft. (1219 m)
User Controls — IC470A, IC471A, and IC472A models only:
(1) DTE/DCE slide switch (default setting
is DCE)
Indicators — None
Connectors — All end-mounted:
RS-232:
IC470A-F, IC471A-F, IC472A-F:
(1) DB25 female;
IC470A-M, IC471A-M, IC472A-M:
(1) DB25 male;
IC473A-F, IC630A-F, IC631A-F:
(1) DB9 female;
IC473A-M, IC630A-M, IC631A-M:
(1) DB9 male;
RS-422:
IC470A and IC473A models:
(1) 5-position terminal block;
IC630A models: (1) RJ-12 (“6-wire
RJ-11”) female;
IC631A models: (1) RJ-45 female;
RS-422/530:
IC471A models: (1) DB25 female;
IC472A models: (1) DB25 male
