PreintstallationInstallationStartupMaintenance
Troubleshooting Guide
MAXIMUM OPERATING DEPTH 555 FEET (169 METERS)
MAXIMUM FLOW RATE - PER MIN UP TO 2.0 US GPM (7.57 LPM)
MAXIMUM FLOW RATE - PER DAY UP TO 2,880 US GPD (10,900 LPD)
MAXIMUM OPERATING PRESSURE 240 PSIG (BASED ON 100 PSI AIR SUPPLY)
MAXIMUM LIFT 555 FEET OF WATER
STROKES PER MINUTE 5 - 40 SPM
MAXIMUM STROKES PER MINUTE 40 SPM
DISCHARGE PER STROKE 0.05 GALLONS (0.19 LITERS)
TEMPERATURE RANGE UP TO 140º F / 60º C
MAXIMUM EXTERNAL DIAMETER 1.9 INCHES (4.83 CENTIMETERS)
TOTAL CYLINDER LENGTH 38 INCHES (96.5 CENTIMETERS)
CONNECTION TO RISER PIPE 1.25 INCHES (3.18 CENTIMETERS)
RECOMMENDED INTERNAL BORE-HOLE DIAMETER 2 - 3 INCHES (5.08 - 7.62 CM) OR GREATER
WEIGHT OF CYLINDER 8 POUNDS (3.63 KILOGRAMS)
DISCHARGE SIZE 1.25 INCHES NPT (3.18 CENTIMETERS)
INSTALLATION ANY ANGLE FROM VERTICAL TO HORIZONTAL
DRIVER WEIGHT 35 POUNDS (15.8 KILGRAMS)
DRIVER ROD WEIGHT 12 LBS PER 100 FT (3.7 KG PER 100 M)
FOOT VALVE ASSEMBLY WEIGHT 8 POUNDS (3.6 KILOGRAMS)
MINIMUM WELL CASING SIZE 2 INCHES (5.08 CENTIMETERS)
PNEUMATIC AIR CONNECTION 3/8 INCH NPT THREADS, 3/8 INCH O.D. TUBING
Blackhawk Technology Company
V-2PneumaticPistonPumpI&O-10365 | 20220811
31
FIGURE 6: Technical Data - 101 Downhole
FIGURE 5: Performance Data - 101 Downhole
