BLACKHAWK! V-2 - Page 34

MAXIMUM OPERATING DEPTH 243 FEET (74 METERS)
MAXIMUM FLOW RATE - PER MIN UP TO 5.4 US GPM (20.4 LPM)
MAXIMUM FLOW RATE - PER DAY UP TO 7,700 US GPD (29,400 LPD)
MAXIMUM OPERATING PRESSURE 105 PSIG (BASED ON 100 PSI AIR SUPPLY)
MAXIMUM LIFT 243 FEET OF WATER
STROKES PER MINUTE 5 - 40 SPM
MAXIMUM STROKES PER MINUTE 40 SPM
DISCHARGE PER STROKE 0.125 GALLONS (0.48 LITERS)
TEMPERATURE RANGE UP TO 140º F / 60º C
MAXIMUM EXTERNAL DIAMETER 2.9 INCHES (7.37 CENTIMETERS)
TOTAL CYLINDER LENGTH 38 INCHES (96.5 CENTIMETERS)
CONNECTION TO RISER PIPE 2 INCHES (5.08 CENTIMETERS)
RECOMMENDED INTERNAL BORE-HOLE DIAMETER 3 - 4 INCHES (7.62 - 10.16 CM) OR GREATER
WEIGHT OF CYLINDER 10 POUNDS (4.53 KILOGRAMS)
DISCHARGE SIZE 2 INCHES NPT (5.08 CENTIMETERS)
INSTALLATION ANY ANGLE FROM VERTICAL TO HORIZONTAL
DRIVER WEIGHT 35 POUNDS (15.8 KILGRAMS)
DRIVER ROD WEIGHT 12 LBS PER 100 FT (3.7 KG PER 100 M)
FOOT VALVE ASSEMBLY WEIGHT 10 POUNDS (4.53 KILOGRAMS)
MINIMUM WELL CASING SIZE 3 INCHES (7.62 CENTIMETERS)
PNEUMATIC AIR CONNECTION 3/8 INCH NPT THREADS, 3/8 INCH O.D. TUBING
Blackhawk Technology Company
V-2PneumaticPistonPumpI&O-10365 | 20220811 32
Appendix
FIGURE 8: Technical Data - 102 Downhole
FIGURE 7: Performance Data - 102 Downhole
