Getting Started with Videohub Controllers
Videohub
Control Panel
Power Source Configuration Maximum
Sources
Maximum
Destinations
Control Style Macros Hardware
Control
Rack Space Depth
Videohub Master Control Power over Ethernet
or international AC
adapter
Mac OS X or Windows
software via USB type
B port
288 288 Direct button
selection and/or
scroll wheel
15 assignable
buttons with
scroll wheel
and LCD
1 RU < 1 inch
Videohub Smart Control Power over Ethernet
or international AC
adapter
Mac OS X or Windows
software via USB type
mini B port
40 sources with
1 destination
20 sources with
20 destinations
X-Y or Cut Bus Up to 10 buttons
can each
change up to 16
crosspoint routes
simultaneously
40
programmable
buttons
1 RU < 1 inch
GPI and Tally Interface International DC
adapter
Mac OS X or Windows
software via USB type
mini B port
8 GPIs 8 GPOs CCU controlled
over serial or
ethernet
- - - -
Choosing a Videohub Controller
Check this table for an overview of each Videohub controller's capabilities to help you decide which model
you will need. You can plan how to set it up so there are no nasty surprises.
