Getting Started with Videohub Routers
Plugging in Video
All SDI connections support auto detection of SD, HD or 3G-SDI, and reclocking on all SDI outputs.
Additionally, both the Smart Videohub 20x20 and Smart Videohub 12x12 also support 6G-SDI for UltraHD
4K video. All Videohub models feature regular-sized BNC ports which make it easy to connect to other SDI
equipment using regular SDI cables. If you're connecting Videohub to SDI equipment which has miniature
SDI connectors, such as DIN 1.0/2.3, we recommend using SDI cables which are terminated with a miniature
connector at one end and a regular BNC at the other.
Installing the Videohub Software
The Videohub software is used to control your router and can be installed on a Mac OS X computer,
Windows computer or even an iPad!
Videohub software runs on the latest Mountain Lion and Mavericks versions of Mac OS X. On the Windows
platform, the software runs on both 32 and 64-bit versions of Windows 7 and Windows 8.
Mac OS X installation
Step 1: Double click the installer file from the supplied CD or from your downloads folder if you
downloaded the software from the Blackmagic Design website.
Step 2: Mac OS X will automatically install the required drivers without user interaction.
Windows installation
Step 1. Double click the installer file from the supplied CD or from your downloads folder if you
downloaded the software from the Blackmagic Design website. The Hardware Wizard will
detect the new hardware.
Step 2. Select “Install the Software Automatically”. Windows will find the Videohub drivers for you.
Step 3. A warning message saying “This software has not passed logo certification” or “The publisher
could not be verified“ may appear during this process. Choose “Continue Anyway” or “Run“.
Mac OS X installation: Follow install prompts.
Windows installation: Follow install prompts.
